Rail Clip
——
Product Categories
——
Details
——
| Code | Applicable guide railsize | A | B | C | D | E | F | G | H | I | |
| GS1-T1 | T45/A, T50/A | M10 | 32 | 22 | 15 | 12 | 5.5 | 5 | 11 | 23 | 2 |
| GS1-T2 | T70-1/B, T75-3/B,T78/B | M12 | 39 | 26 | 19 | 15 | 7.3 | 6.5 | 13 | 27 | 3 |
| GS1-T3 | T89/B, T90/B | M14 | 45 | 29 | 21 | 18.5 | 9.5 | 8 | 13 | 34 | 4 |
| GS1-T4 | T114/B, T127-1/B | M16 | 50 | 34 | 22 | 20.5 | 10.5 | 8.5 | 15 | 40 | 4 |
| GS1-T5 | T127-2/B, T140-1/B,T140-2/B | M18 | 55 | 37 | 22 | 23 | 13 | 11 | 17 | 42 | 4 |
Anchor Bolt
——
Details
——
| Code | Specifications | Diameter | Sleeve length | Drill Diameter |
| GS1-650 | M6*50 | 9.5 | 30 | 9.5 |
| GS1-865 | M8*65 | 12 | 35 | 12 |
| GS1-870 | M8*70 | 12 | 35 | 12 |
| GS1-1070 | M10*70 | 14 | 35 | 14.5 |
| GS1-1080 | M10*80 | 14 | 35 | 14.5 |
| GS1-10100 | M10*100 | 14 | 35 | 14.5 |
| GS1-10120 | M10*120 | 14 | 35 | 14.5 |
| GS1-12100 | M12*100 | 17.3 | 50 | 18 |
| GS1-12120 | M12*120 | 17.3 | 50 | 18 |
| GS1-12150 | M12*150 | 17.3 | 50 | 18 |
| GS1-12200 | M12*200 | 17.3 | 50 | 18 |
| GS1-16100 | M16*100 | 21.7 | 50 | 22 |
| GS1-16120 | M16*120 | 21.7 | 60 | 22 |
| GS1-16150 | M16*150 | 21.7 | 60 | 22 |
| GS1-16200 | M16*200 | 21.7 | 60 | 22 |
| GS1-20160 | M20*160 | 25.4 | 80 | 26 |
| GS1-20200 | M20*200 | 25.4 | 80 | 26 |
| GS1-22160 | M22*160 | 28.6 | 90 | 29 |
| GS1-24200 | M24*200 | 31.8 | 110 | 33.1 |
